HG047HD016: 4.66-inch is an RGB interface, TFT, full view, 720*1280 resolution portable TFT display, suitable for handheld devices
Product description
4.66in is an RGB interface, TFT, full view, 720*1280 resolution portable TFT display, suitable for handheld devices.
Product parameter details
| Model | HG047HD016 | Application industry | Medical handheld |
| Size | 4.66 inch | Arrangement | 720*1280 |
| Display size | 58.1mm*103.3mm | External dimensions | 61.1mm*111.15mm*1.56mm |
| Viewing Angle | ALL | Luminance | 320cd/m2(customizable) |
| Contrast ratio | 800 | NTSC | 70% |
| Signal types | MIPI interface 24PIN |
| Temperature | Operating temperature; -20℃ ~ + 70℃, Storage temperature: -30℃ ~ + 80℃ |
| Remark: | |
Description of products
TFT is 4.7-inch HG047HD016 portable TFT display, resolution is 720*1280,
The display effect is IPS, and full fitting process can also be done.
It is composed of TFT LCD panel, driver IC, FPC and backlight.
Using MIPI-4 channel interface 24PIN, can work in -20℃~70℃, storage temperature: -30℃~80℃;
This product is widely used in industrial control, medical, handheld, security, vehicle, VR, instrumentation and other related products
All products are available with or without touch and industrial drive boards, no matter what configuration you choose,
Can be customized according to your requirements (can be customized backlight, FPC, touch screen, industrial drive board)
Comply with RoHS and CE certification standards;
If you can't find a suitable one, please contact us for a recommendation.
